Piezas de maquinaria de Guangzhou Menzeh Co., Ltd.
| Lugar de origen: | GUANGZHOU CHINA |
| Nombre de la marca: | MENZEH GEARS |
| Certificación: | CE |
| Número de modelo: | 31E9-01050 31N8-12010 31Q9-19140 XKAH-01597 31Q8-10142 31N8-10123 R290 R330 R320 |
| Cantidad de orden mínima: | 1pc |
|---|---|
| Precio: | Negotiated |
| Detalles de empaquetado: | CAJA, caso de madera |
| Tiempo de entrega: | 1-3 días laborables |
| Condiciones de pago: | Western Union, T/T, L/C, PAGA de ALI |
| Capacidad de la fuente: | 500 PC por día |
| Nombre de parte: | Caja de cambios del oscilación | Número de parte: | 31E9-01050 31N8-12010 31Q9-19140 XKAH-01597 31Q8-10142 31N8-10123 |
|---|---|---|---|
| Utilizado para: | R290 R330 R320 | Condiction: | Todo el nuevo OEM |
| Garantía: | 3 meses | Envío: | Envío del AIRE de MAR de la UPS de DHL TNT/ |
| Puerto: | Huangpu Guangzhou | Después de garantía: | Recambios de la ayuda en línea video del soporte técnico |
| Alta luz: | R320 excavador Swing Reduction Gearbox,R330 excavador Swing Reduction Gearbox,31Q8-10142 excavador Swing Gearbox |
||
excavador Swing Reduction Gearbox de 31E9-01050 31N8-12010 31Q9-19140 XKAH-01597 31Q8-10142 31N8-10123 R290 R330 R320
| Nombre de parte | Caja de cambios del oscilación |
| Número de parte. | 31E9-01050 31N8-12010 31Q9-19140 XKAH-01597 31Q8-10142 31N8-10123 |
| Utilizado para | R290 R330 R320 |
| Garantía | 3 meses |
| Después de garantía | Recambios libres de la ayuda en línea video del soporte técnico |
| Posición. | Número de parte | Qty | Nombre de piezas | Comentarios |
| *. | @ | [1] | MONTAJE DEL MOTOR DEL OSCILACIÓN | VEA 4100 |
| N*-2. | 31E9-01050 | [1] | ENGRANAJE DE REDUCCIÓN DEL OSCILACIÓN | SB-I-2008-008.PDF |
| N*-2. | 31E9-01051 | [1] | ENGRANAJE DE REDUCCIÓN DEL OSCILACIÓN | SB-I-2008-008.PDF |
| N*-2. | 31E9-01052 | [1] | ENGRANAJE DE REDUCCIÓN DEL OSCILACIÓN | SB-I-2008-008.PDF |
| N1. | XKAQ-00063 | [1] | CASING-FRONT | |
| 1 | XKAQ-00112 | [1] | CASING-FRONT | |
| 1 | XKAQ-00141 | [1] | CASING-FRONT | |
| 1 | XKAQ-00279 | [1] | CASING-FRONT | |
| 1 | XKAQ-00329 | [1] | CASING-FRONT | |
| 2 | XKAQ-00003 | [1] | CASING-MIDDLE | |
| 3 | XKAQ-00004 | [1] | SHAFT-DRIVE | |
| 3 | XKAQ-00328 | [1] | SHAFT-DRIVE | |
| 4 | XKAQ-00006 | [1] | GEAR-RING 2 | |
| 5 | XKAQ-00022 | [3] | GEAR-PLANET 2 | |
| 6 | XKAQ-00062 | [1] | SOL GEAR-2 | |
| 6 | XKAQ-00012 | [1] | SOL GEAR-2 | |
| 7 | XKAQ-00008 | [1] | GEAR-RING 1 | |
| 8 | XKAQ-00024 | [3] | GEAR-PLANET 1 | |
| 8 | XKAQ-00137 | [3] | GEAR-PLANET 1 | |
| 9 | XKAQ-00009 | [1] | SOL GEAR-1 | |
| 9 | XKAQ-00061 | [1] | SOL GEAR-1 | |
| 10 | XKAQ-00016 | [1] | PORTADOR | |
| *-1. | XKAQ-00021 | [3] | PIN ASSY NO.2 | |
| N11. | XKAQ-00060 | [3] | PIN ASSY-2 | |
| N32. | XKAQ-00046 | [3] | BUJE 2 | |
| 12 | XKAQ-00059 | [6] | WASHER-THRUST | |
| 13 | XKAQ-00058 | [1] | BUTTON-THRUST | |
| 14 | XKAQ-00019 | [3] | PIN 1 | |
| 14 | XKAQ-00136 | [3] | PIN ASSY 1 | JAULA DE LA AGUJA DEL INC. |
| 15 | XKAQ-00057 | [3] | PLATE-SIDE 1 | |
| 16 | XKAQ-00056 | [4] | IMÁN | |
| 17 | XKAQ-00055 | [1] | PLATE-SIDE 3 | |
| 18 | XKAQ-00054 | [1] | BAR-GAUGE | |
| 18 | XKAQ-00034 | [1] | BAR-GAUGE | |
| 19 | XKAQ-00035 | [1] | PIPE-GAUGE | |
| 20 | XKAQ-00017 | [1] | RING-SPACER | |
| 20 | XKAQ-00111 | [1] | RING-SPACER | |
| 21 | XKAQ-00053 | [4] | PIN-KNOCK | |
| 21 | XKAQ-00053 | [2] | PIN-KNOCK | |
| 22 | XKAQ-00028 | [1] | BEARING-ROLLER | |
| 23 | XKAQ-00027 | [1] | BEARING-ROLLER | |
| 24 | XKAQ-00030 | [3] | CAGE-NEEDLE | |
| 25 | XKAQ-00052 | [16] | BOLT-SOCKET | |
| 26 | XKAQ-00051 | [12] | BOLT-SOCKET | |
| 27 | XKAQ-00033 | [1] | SEAL-OIL | |
| 27 | XKAQ-00138 | [1] | SEAL-OIL | |
| 27 | XKAQ-00280 | [1] | SEAL-OIL | |
| 27 | XKAQ-00330 | [1] | SEAL-OIL | |
| 28 | XKAQ-00050 | [3] | PIN-SPRING | |
| 29 | XKAQ-00049 | [1] | ENCHUFE | |
| 30 | XKAQ-00048 | [3] | PIN-SPRING | |
| 31 | XKAQ-00047 | [1] | RING-STOP | |
| 33 | XKAQ-00045 | [1] | RING-STOP | |
| 34 | XKAQ-00044 | [2] | WASHER-LOCK | |
| 34 | XKAQ-00292 | [1] | WASHER-LOCK | |
| 35 | XKAQ-00013 | [1] | GEAR-PINION | |
| 36 | XKAQ-00043 | [1] | PLATE-LOCK | |
| 36 | XKAQ-00296 | [1] | PLATE-LOCK | |
| 37 | XKAQ-00042 | [4] | BOLT-HEX | |
| 37 | XKAQ-00042 | [2] | BOLT-HEX | |
| 38 | XKAQ-00041 | [3] | RING-STOP | |
| 39 | XKAQ-00040 | [3] | PLATE-SIDE 2 | |
| 40 | XKAQ-00109 | [1] | ANILLO DE RETENCIÓN | |
| 41 | XKAQ-00110 | [1] | V-SEAL | |
| 42 | XKAQ-00143 | [1] | RESPIRADERO DE POST-AIR | |
| N. | @ | [1] | PIEZAS NO SUMINISTRADAS |
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
